Flooring uv coating
The surface coating of flooring is mainly based on two-component PU paint and single component polyurethane wet curing. Later, the emergence of UV paint helped flooring achieve large-scale and industrial production. However, the traditional UV paint construction process for flooring is cumbersome and costly, which is an important challenge faced by flooring enterprises in the era of internal rolling. Mickey Paint launches ultra durable floor UV paint, which can be coated, packaged and stored in just 2-5 steps, replacing the traditional 8-11 layers.
Product Introduction
Flooring UV coating is a UV curable coating based on acrylate resin, combined with photoinitiators and additives. It cures instantly under UV light. It is eco-friendly, efficient, high hardness and wear-resistant, widely used for surface coating of various floors.
Application Scope
1.Solid wood flooring, engineered wood flooring, laminate flooring
2.SPC flooring, WPC flooring, PVC flooring
3.Bamboo flooring, outdoor wood flooring
4.Stair treads, wood furniture panels
Performance Characteristics
1.Fast curing: fully cured in 1–3 seconds under UV light.
2.High hardness & wear resistance: pencil hardness 2H–6H.
3.-friendly: low VOC, formaldehyde-free, heavy metal-free.
4.Excellent adhesion: no peeling or cracking.
5.Stain-proof, moisture-proof, easy to clean.
6.Anti-yellowing and good weather resistance.
Physical data
|
Parameter Item
|
Value
|
|
Appearance
|
Transparent / slightly turbid liquid
|
|
Solid Content
|
100%
|
|
Density
|
1.1–1.2 g/cm³
|
|
Viscosity (25°C, #4 cup)
|
Primer: 80–150 s, Topcoat: 150–300 s
|
|
Pencil Hardness
|
2H–6H
|
|
Adhesion (Cross-cut)
|
Grade 1
|
|
Abrasion (Taber)
|
≤40 mg / 1000 R
|
|
VOC
|
<5 g/L
|
|
Curing Energy
|
Primer: 150–300 mJ/cm², Topcoat: 600–1000 mJ/cm²
|
Coating Process
English Steps
1.Substrate preparation: sand 240#–400#, clean and dust-free.
2.Preheat (if <15℃): 25–35℃.
3.Roller coat primer: 4–6g/m².
4.UV cure 1–2s.
5.Intermediate coat (optional): putty → sand → coat 6–8g/m² → cure.
6.Roller coat topcoat: 8–12g/m².
7.Level at 60–80℃ for 1–2min.
8.UV cure 2–3s finished.
9.This process is for reference only. For specific painting steps, please consult our company
Coverage
| Coat |
Coverage |
|
|
|
| Sanding primer |
25–125 g/m² |
| Topcoat |
8–12 g/m² |
Note: Actual consumption varies slightly by substrate and process.
Pruduct advantag
Design and Structural Integration Advantages in Flooring Systems
The flooring UV coating’s formulation offers a highly adaptable system suitable for incorporation into automated finishing lines, supporting seamless layer application including primers and topcoats. Its 100% solids content facilitates uniform thickness control essential for consistent gloss and wear resistance in wood floor coating applications. Collaboration with experienced uv coating manufacturers ensures the coating maintains optimal viscosity and curing parameters compatible with diverse substrate types, including demanding SPC floor materials. The absence of harmful chemicals such as formaldehyde and heavy metals aligns with contemporary environmental standards, reinforcing its position as a responsible choice from designated uv coating factories committed to sustainable manufacturing solutions.
Enhanced Performance and Practical Value in Industrial Environments
Operational simplicity is reinforced by the coating’s rapid UV curing, enabling reduced downtime and faster throughput in production facilities in floor varnish and floor coating applications. Its high pencil hardness results in improved abrasion resistance crucial for commercial and residential traffic conditions. The formulation offers excellent adhesion and stain resistance, minimizing defects and post-application maintenance. From a compliance perspective, low VOC emissions support environmental certification efforts. The product’s adaptability across multiple flooring substrates, including uv coating for SPC floor, provides versatility and reduces the need for multiple coating products, enhancing inventory and procurement efficiency for flooring system integrators.
FAQ
What types of floors are compatible with your Flooring UV coating?
We produce floor coating solutions compatible with solid wood, engineered wood, laminate, SPC, WPC, PVC, bamboo floors, and outdoor wood flooring. Our uv coating ensures strong adhesion and durability across these substrates, meeting the requirements of various industrial floor finishing applications.
Can you customize Flooring UV coating formulations for specific projects?
Yes, we offer tailored formulations for our uv coating products to meet your project's unique needs. Our R&D center can adjust hardness, curing times, and additives to suit different floor types or environmental conditions, ensuring optimized performance in your application.
What is the recommended curing time for Flooring UV coating under UV light?
Our Flooring UV coating cures rapidly under UV light, achieving full cure in just 1–3 seconds for the top coat. Primer curing takes slightly longer, from 80 to 150 seconds. This fast curing time helps improve production efficiency without compromising coating hardness or durability.
How do you ensure timely delivery and support for bulk orders of your floor varnish?
We maintain large-scale production lines and a finished product warehouse to fulfill bulk orders of our floor varnish promptly. Our logistics can support both local and international shipments, ensuring reliable supply. For detailed scheduling and order customization, contact our sales team directly.
